Guangzhou Baiyou Stage Lighting Technology Co., Ltd., is set research and development, production, sales, service in the integration of production-oriented enterprises, the main production stage lighting equipment, moving head light, follow spot series, laser series, LED high-power series, lighting series, LED effect, oil smoke cigarette machine, stage equipment, console series, accessories series and so on. Widely used in stage, dance halls, KTV rooms, radio, television, opera, film and television entertainment places, etc. No matter in product variety, quality process, and production capacity, technical content, has accumulated rich experience, for different levels of the different needs of customers to provide quality products and services.
PRODUCT SHOW
1200 w moving head light BY - M1200A (16 ch)
Detail Info

Model BY - M1200A


Technical parameters


Voltage: AC220-230 - v 50-60 hz (can be customized according to customer's requirement)


Bulb: HMI1200W/S short arc discharge bubble: the total power of 1500 w


Insurance: to be 20 a


Color temperature: 6500 k


The lamp holder, high temperature resistant plastic king


The dimension of lamps and lanterns: L500 * H760mm W410


Carton size: L620 * H900mm W605


Air box size: L610 * H910mm W480


49 kg net weight: the gross weight: 62 kg


The performance characteristics of


In compliance with CE standard and GB7000.15-2000 standard


16 control channel; Standard DMX512 signal.


LCD liquid crystal display system in English, can be very intuitive set personalized features.


A color plate, white + 7 color, one-way rainbow effect,


Speed is adjustable.


Fixed pattern plate 1 with pattern jitter,


One-way flow effect, the speed is adjustable.


One has design pattern plate rotating jitter, one-way


Water effect, the speed is adjustable. Pattern can be arbitrary replacement.


A prism plate Prism combination creature phantom effect,


Prism positive &negative free control, built-in macro effect.


0 ~ 100% linear mechanical dimmer, stroboscopic speed 1 ~ 12 times per second.


Electric light figure 5 ~ 100% linear adjustable beam size.


Electronic linear focusing 2 meters to infinite


Level 16 bit resolution 450 °, 270 ° vertically 16 bit resolution


Horizontal vertical light lotus root reset system, after the misoperation accident happen, can automatically retrieve place


Good heat dissipation system fully, and overheating protection measures


With photoelectric detection, light soaking time delay, has protective function to the lamp and control system, improve the stability of lamps and lanterns


By external console or light devices end plate control window, edit the storage to the CPU in the body of the program,


No programming controller can also run or run a program, can store eight scenes.


Security code is set for the customer, can display light bulbs and lamps and lanterns use time
